Application of acid discharge pump in hydrochloric acid transportation

As one of the three industrial strong acids, hydrochloric acid is widely used in industrial production. Concentrated hydrochloric acid and dilute hydrochloric acid have high requirements for pump materials. In fact, hydrochloric acid pump is a very broad concept.The classification of hydrochloric acid pump is different under different process and functional conditions.

Hydrochloric acid has many important applications in chemical engineering and plays a decisive role in product quality. Hydrochloric acid can be used in pickling steel, and it is also a chemical reagent needed to prepare many inorganic and organic compounds, such as vinyl chloride in polyvinyl chloride plastics. Hydrochloric acid has many small-scale uses, such as household cleaning, production of food additives such as gelatin, detergents and leather processing. The world produces about 20 million tons of hydrochloric acid every year.

1.The pump used in the hydrochloric acid process is called the hydrochloric acid pump.

2.Hydrochloric acid self-priming pump for transportation and lifting process.

3.Unloading process: hydrochloric acid magnetic pump; hydrochloric acid self-priming pump.

4.Used in precision dosing process: hydrochloric acid quantitative dosing pump.

5.If hydrochloric acid contains a small amount of impurities: hydrochloric acid pneumatic diaphragm pump.

In the process of loading and unloading hydrochloric acid, we can use acid unloading pump and acid-alkali resistant pump. The self-priming pump can transport hydrochloric acid to the tanker because of its strong self-priming ability, while the magnetic pump is suitable for transporting this expensive and highly corrosive liquid because of its non-leakage characteristics. The choice of these two types depends on the installation method. If the pump is installed at the bottom of the tanker, the self-priming capacity is not required. Select a magnetic pump. If installed on top of an oil tanker with high lift, a self-priming pump is required, which is the choice of pump type.

The material of the water pump is selected according to the concentration of hydrochloric acid, the type of the pump is selected according to the hydrochloric acid process; the type of the pump is selected according to the flow rate and head: hydrochloric acid is divided into dilute hydrochloric acid and concentrated hydrochloric acid. I can choose PRPP plastic pump. If it is concentrated hydrochloric acid, you need to choose PVDF plastic pump.
