RT- chemical storage tank

PLASTICS FEATURES

• Volume:1m³~300m³
• Working Pressure:0.2 MPa~100 MPa
• Medium:Chemical process liquid, acid-base liquid, condensate
• Material:Carbon steel / stainless steel / custom made
• Type:Vertical or Horizonal

SPECIFICATIONS

• The bottom structure can be divided into:

1.flat bottom

2.Oblique bottom (outerinclination and innerinclination)

3.Cone bottom (90° and 120°)with metal support

• The top structure can be divided into:

1.Open Storage Tank: No Cover

2.Closed storage tank: vertical cylindrical, diameter > 1000mm,manhole with DN500, with conical or flat top cover structure

PTFE lined tanks also called PTFE Tank .The tank is made of carbon steel or stainless steel. The inner wall of the tank is made of rust -spraying, brushing, patch, welds and other procedures for forming a four -fluoride plate and steel container. PTFE has excellent chemical properties and chemical stability. It can resist strong alkali and strong acid and organic solvent corrosion, wider temperature resistance and lubrication, and non -viscosity.

PTFE lined tanks such as storage tanks, transport tanks, mixing tanks, ISO rated tanks and day tanks are fabricated. PTFE lined tanks are used in chemical processing, semiconductor, water processing, pharmaceutical, food, biotechnology and pulp/paper applications.

For more details or quotations, please contact us and leave your contact information.
